Greenhouses, Climate houses etc.
1. The whole set of lumiaire consist of lamp, ballast and fixture.
2. The voltage of ballast is optional and meets the standard of different market.
3. The wattage of light is adjustable by the button of the ballast.
4. The blue light output boost the growth of leaves of plant.
5. 3 years warranty.
6. With ETL and CETL listed.
Disconnect the product from mains before performing any maintenance or repairment.
Wait 20 mins before activating the fixture after maintenance or repairment.
Do not touch the lamp with bare hands.
Check the wiring of the products regularly to ensure the product works safely.
| Dimension(Note: Error limit± 2) | |||
| Description | Reflector L*W*H(mm): | Packaging L*W*H(mm): | G.w. (Kg) |
| 315W CMH-2 | 234*305*115 | 500*270*260 | 4.8 |
| 315W CMH-2A | 225*275*90 | 480*280*250 | 3.9 |
| 315W CMH-8 | 225*275*90 | 530*290*160 | 3.6 |
| 315WCMH Lamp | |
| Voltage [M] | 100/115 |
| Current [A] | 1.55 |
| Wattage [W] | 315 |
| Lumens(Wholeluminaire)[Im] | 38918 |
| Power Factor | ≥0.98 |
| Bulb Type | PGZ18 |
| CCT[K] | 3000K/4000K |
| CRI [Ra] | 90 |
| Rated Frequency[HZ] | 50/60 |
| PPFD[Umol/slw] | 1.68 |
| PRF [mw] | 111750 |
| Peak Wavelength[nm] | 536 |
| Average Life [hrs] | 12000 |
| 315W-2(A)/315W-5/315W-6 Ballast | |
| Input Voltage[V] | 120-240/220-277 |
| Input Frequency[HZ] | 50/60 |
| Input Power Factor | ≥0.98 |
| THD[%] | ≤10 |
| Wave Crest Ratio | ≤1.7 |
| Starting Time[S] | 5 Max |
| Pulse Voltage [KV] | 4-5 |
| Output Rated Frequency[KHZ] | 110 |
| Open Circuit Voltage[V] | ≤440 |
| Efficiency[%] | ≥92% |
Years Of Experience
Universelite Co., Ltd. is a professional 315W Ceramic Metal Halide Grow Light(CMH) Company and 315W Ceramic Metal Halide Grow Light(CMH) Company
Universelite provides full ranges of HID, EDL and LED lightings, including Grow Lamp series, Street and Road Lighting series, Fishing Lamps, Aquarium Lighting series, Commercial Lighting series, EDL and LED products. The main products include High Pressure Sodium Lamp, High Pressure Mercury Lamp, Metal Halide Lamp, PAR lamp, elctrodeless lamp, EDL ballast and LED lamps, etc. The products are made of imported high quality materials with advanced equipments, cut-edge technologies and workmanship, and are of high lumen efficiency, long service life, energy saving and environmental friendly. The products have been selling successfully into Europe, North America, Australia, Southeast Asia, and other countries of the world.
Products have a variety of certification，
CCC, CE, FCC, CB, UL, CUL
ISO9001-2008/ISO14000
Focus on the field of lighting and serve the lighting industry at home and abroad.
