Custom 40w LED Station Light

Home / Product / LED Canopy/Garage Light / 40w LED Station Light
40w LED Station Light
  • 40w LED Station Light
  • 40w LED Station Light
  • 40w LED Station Light
  • 40w LED Station Light
  • 40w LED Station Light
  • 40w LED Station Light
  • 40w LED Station Light

40w LED Station Light

1.Die- -casting aluminum body,outer surface with spray paint treatment, elegant appearance and excellent heat dissipation.
2.Long life, low thermal resistance and low power consumption.
3.Used design of US general junction box,easy operating.
Contact Us Shopping Cart Inquiry Download
  • Item description LEDYZ40W001 iLEDYZ60W001 iLEDYZ85W001 LEDYZ100W001 LEDYZ120W001
    Dimensions [mm]   226*226*105 (L*W*H) 343*343*113 (L*W*H)
    Chip CREE/LG/PHILIPS
    Driver  Mean Well/Inventronics/UVL
    Input voltage [VAC]  1100-277VAC 1100-277VAC '100-277VAC I100-277VAC 1100-277VAC
    Inqut current [A]  0.35 (120V) 0.5 (120V) 0.7 (120V) 0.85 (120V) 1.0 (120V)
    Input watt [W]  40±5% 60±5% 85±5% 100±5% 120±5%
    Power factor >0.95 >0.95 >0.95 >0.95 >0.95
    Voltage [V] 27 30 75 30 27
    Current(reference) [A]  1.3 1.8 1 3 4.1
    Wattage(reference) [W]  35 ±5% 53±5% 72±5% 90±5% 110±5%
    Power efficiency ≥86% ≥88% ≥85% ≥90% ≥92%
    Luminous flux [Lm]  3400 5200 7900 9500 11500
    Colour temperature [K]  4000-5700K 2700-5700K 3000-5700K 3000-5700K 3000-5700K
    Colour index [Ra]  ≥70 ≥70 ≥70 ≥70 ≥70
    Lumen maintenance(2000h) [%] 98 98 98 98 98
    Average life [h]  50000 50000 50000 50000 50000
    Net weight [Kg] 3.2/set 3.2/set 5.7/set 5.7/set 5.85/set
    Gross weight [Kg] 3.6/set 3.6/set 6.3/set 6.3/set 6.5/set
    Environment WET WET WET WET WET
    Ambient Temperature [℃] -25°C-40°C Warranty 5years
    Burning position vertically downward 土 15°
